Cummins Commercial Generator 120kW IP23 Industrial Cummins Diesel Generator set
AI power USA series generator set adopts USA engine as the power source. it’s a global power leader who is devoted to the engine R&D and manufacturer since 1919 in Columbus, now it has become the largest engine manufacturer in the world providing more than 160 countries sales and aftersales service. Ai Power AC series generator has adopted DCEC and CCEC engine include 4B, 6B, 6C, 6L, NTA, MTA, KTA series etc.
Engine Specifications:
| Manufacturer | Dongfeng Cummins Engine Co., Ltd. |
| Model | 6BTAA5.9-G12 |
| Engine speed | 1500rpm |
| Engine power | |
| Standby power | 155kw / 207HP |
| Base output power | 140kw / 187HP |
| Aspiration | Turbocharged & Charge Air Cooled |
| Cylinder quantity | 6 |
| Bore * Stroke | 102*120mm |
| Displacement | 5.9L |
| Fuel system | BYC P7100/Electronic Governor |
| Governor Regulation | ≤5% |
| Low idle | 750-850 rpm |
| Piston speed | 6.0 m/s |
| Friction energy output | 12.7 kw |
Alternator Specifications:
| Alternator manufacturer | Xiamen Ai Power Technology Co., Ltd. |
| Alternator brand | AI POWER |
| Alternator model | AI274EC |
| Control system | SELF EXCITED |
| A.V.R. | Included |
| Voltage regulation | ±1.0% |
| Insulation system | Class H |
| Protection | IP23 |
| Rated power factor | 0.8 |
| Winding pitch | Two thirds |
| Winding leads | 12 |
| Frequency (Hz) | 50 |
| Voltage (V) | 400 |
| Phase | 3 |
| Output ratings (kVA/kW) | |
| ----------------Cont.H-40°C | 150/120 |
| ----------------Standby-27°C | 165/132 |
| THF | <5% |
| TIF | <50 |
| Max. overspeed (Rev/Min) | 2250 |
| Bearing | Single |
Product Overviews
Product Details
The tank is of hermetically sealed design and is made from corrugated steel sheets. This type of construction allows a degree of flexibility that is needed to accommodate the expansion and contraction of oil due to varying service conditions. The tank cover is bolted to the body of the tank. The surface is shot blasted first to eliminate all signs of rust, welding spatters, greese, oil and mill scale to achieve a good abrasive surface for the paint to hold for a long period of time. The two coats of primer paint are applied followed by one coat of standard "Cement Gray" (RAL 7033). (Colour Code can be customized)
The regular accessories include:
1. Oil conservator (available on request, usually used for ratings above 2000kva)
2. Temperature indicator
3. Pressure release valve
4. Oil level indicator
5. Oil drain valve
6. Oil Sample valve
7. Earthing device
8. Lifting lug
9. cable box
1. Can you accept small order?
A: Yes, we can accept trial order, it is the starting of business. But according to different product the price may be higher as normal quantity.
2. What is your company product range?
A: We are a professional turbocharger supplier, OEM and ODM are welcome.
3. Do you inspect the product? How?
A: Yes, each step of production and finished products will be carried out inspection by QC before shipping.
4. What is your payment terms?
A: T/T 30% advance payment, the balance 70% shall be paid before shipment, L/C at sight.
5. What about your factory production capacity?
A: 200pcs per month.
6.What kind of transactions you can accept?
A: We can accept FOB, CIF, CFR.
Product Tags:
|
|
120kW IP23 Marine Cummins Backup Generator 6BTAA5.9-G12 Images
|
